Hoshizaki F-2001MRJZ3 flaker icemaker with URC-22FZ, remote-cooled, stainless steel design.

Hoshizaki F-2001MRJZ3 with URC-22FZ, Flaker Icemaker, Remote-cooled

by Hoshizaki
Save 45% Save 45%
$26,370.00
$26,370.00 - $26,370.00
$26,370.00
$14,503.50
$14,503.50 - $14,503.50
$14,503.50

Delivery time

5-8 Business Days

Secure Checkout

Secure online checkout. We do not store customer payment data.

Contact Us

Business Hours: 9 AM - 5 PM CST

Phone: (409) 248-2480

Email: hi@globalmina.com

The F-2001MRJZ3 is capable of producing approximately 2098 lbs of flaked ice per day. Flaked ice is perfect for salad bars, seafood counters, and other food displays that require long lasting sanitary ice. This Remote-cooled with URC-22FZ icemaker features the Advanced CleanCycle24™ design plus a greaseless bearing auger construction making it simple to maintain. The F-2001MRJZ3 requires a Three phase, 208-230v/60/3, 4 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection that is hard-wired at the installation site. Remote condenser sold separately. Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650. Please consult the Specification Sheet for additional details. F-D-2001200MRJ.

Specifications

  • Dimensions: 30″ W x 27-1/2″ D x 34-7/16″ H
  • Up to 2098 lbs of ice produced per 24 hours
  • Mount 2 units side-by-side for 2x the ice production
  • Produces flaked ice
  • Durable stainless steel exterior
  • Compatible bins & dispensers, sold separately: B-250, B-500, B-700, B-800, B-900, B-1150, B-1300, B-1500, B-1650, B-1300, B-1500, B-1650
  • 2 second rinse every hour to remove sediment
  • Advanced CleanCycle24™ design
  • Designed for long life dependability
  • R-404A refrigerant (8 lbs. 2.5 oz. / 3700 g)
  • Heat Rejection:19500 BTU/hr
  • Ambient temperature range: 45 – 100°F
  • Water temperature range: 45 – 90°F
  • Water pressure: 10 – 113psig
  • Voltage range: 187 – 253V
  • 18.1 amps (20 Amp Max fuse)
  • 3.9 kwh/100 lbs.@ 90/70
  • Three phase, 208-230v/60/3, 4 wire, including ground. Must be hardwired at site, no cord/plug included
  • Clean ice and easy maintenance lead to longer unit life span
  • Three Years: Parts & Labor warranty on entire machine.
  • Five Years: Parts warranty on Compressor, air-cooled condenser coil

Additional information

Weight 360 lbs
Dimensions X X in
Warranty |Three Years: Parts & Labor warranty on entire machine.||
Electrical Specs: Three phase, 208-230v/60/3, 4 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 18.1, Max Fuse/HACR Breaker: 20 A
Plumbing Specs: 1/2" FPT Inlet, Minimum 1/4" Nominal ID Copper Water Tubing or Equivalent, 3/4" FPT Outlet, Minimum 3/4" Nominal ID Hard Pipe or Equivalent
Utility Consumption: 3.9 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Operating Limits: Ambient Temp Range: 45 - 100°F, Water Temp Range: 45 - 90°F, Water Pressure: 10 - 113psig, Voltage Range: 187 - 253V, Heat Rejection: 19500 BTU/hr, Refrigerant Charge: R-404A, (8 lbs. 2.5 oz. / 3700 g)

Service Literature

Specification Sheet

Instruction Manual

Parts Manual

CAD/Revit Files

Warranty Statement

Sales Catalog

Video
