Hoshizaki F-500BAJ flaker icemaker with built-in storage bin and stainless steel exterior.

Hoshizaki F-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage Bin

Name: Hoshizaki F-500BAJ, Flaker Icemaker, Air-cooled, Built in Storage Bin
Brand: Hoshizaki
SKU: F-500BAJ
Price: 7876.0 USD
Availability: InStock

by Hoshizaki

Save 45%

$14,320.00

$14,320.00 - $14,320.00

$14,320.00

$7,876.00

$7,876.00 - $7,876.00

$7,876.00

Quantity

Delivery time

5-8 Business Days

Secure Checkout

Secure online checkout. We do not store customer payment data.

Business Hours: 9 AM - 5 PM CST

Phone: (409) 248-2480

Email: hi@globalmina.com

The F-500BAJ is capable of producing approximately 536 lbs of flaked ice per day. Flaked ice is perfect for salad bars, seafood counters, and other food displays that require long lasting sanitary ice. This Air-cooled, Self Contained, Built in Storage Bin icemaker stores up to 170 lbs of ice*. It features an Automatic system flush when bin control is activated plus a greaseless bearing auger construction making it simple to maintain. The F-500BAJ requires a Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included electrical connection. Front in, front out airflow. Please consult the Specification Sheet for additional details.*Rated in accordance with AHRI Standard 820(I-P). Capacity based on 100% of total volume x 30 lb/ft3 average density of ice.

Specifications

Dimensions: 38-1/8″ W x 29-1/8″ D x 42″ H
Up to 536 lbs of ice produced per 24 hours
Up to 170 lbs of built-in storage capacity (5.7ft3)
Produces flaked ice
Durable stainless steel exterior
Front in, front out airflow
Gear motor protected from overload
Automatic system flush when bin control is activated
Designed for long life dependability
R-404A refrigerant (1 lbs. 0.6 oz. / 470 g)
Heat Rejection:2500 BTU/hr
Ambient temperature range: 45 – 100°F
Water temperature range: 45 – 90°F
Water pressure: 10 – 113psig
Voltage range: 104 – 127V
13.8 amps (20 Amp Max fuse)
5.05 kwh/100 lbs.@ 90/70
Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included
Clean ice and easy maintenance lead to longer unit life span
Three Years: Parts & Labor warranty on entire machine.
Five Years: Parts warranty on Compressor, air-cooled condenser coil.

Additional information

Weight	265 lbs
Dimensions	X X in
Warranty	\|Three Years: Parts & Labor warranty on entire machine.\|\|
Electrical Specs:	Single phase, 115v/60/1, 3 wire, including ground. Must be hardwired at site, no cord/plug included, Amperage: 13.8, Max Fuse/HACR Breaker: 20 A
Plumbing Specs:	1/2" FPT Inlet, Minimum 1/4" Nominal ID Copper Water Tubing or Equivalent, 3/4" FPT Outlet, Minimum 3/4" Nominal ID Hard Pipe or Equivalent
Utility Consumption:	5.05 kWh per 100 lbs @ 90/70, 12 gal of Potable Water per 100 lbs @ 90/70
Operating Limits:	Ambient Temp Range: 45 - 100°F, Water Temp Range: 45 - 90°F, Water Pressure: 10 - 113psig, Voltage Range: 104 - 127V, Heat Rejection: 2500 BTU/hr, Refrigerant Charge: R-404A, (1 lbs. 0.6 oz. / 470 g)
